Delta scale

The δ (delta) scale is a non-octave repeating musical scale. It may be regarded as the beta scale's reciprocal, since it is "as far 'down' the (0 3 6 9) circle from α as β is 'up'". As such it would split the minor second (presumably 16:15) into eight equal parts of approximately 14 cents each . This would total approximately 85.7 steps per octave.

The scale step may also precisely be derived from using 50:28 (25:14, 1003.8 cents, A, ) to approximate the interval , which equals 6:5 (E, 315.64 cents, ). Thus the step is approximately 13.946 cents, and there are 86.049 steps per octave.

$$\begin{align} \frac{50\log_2{\left(\frac32\right)} + 28\log_2{\left(\frac54\right)} + 23\log_2{\left(\frac65\right)}}{50^2+28^2+23^2} = 0.011\,621\,2701 \\ 0.011\,621\,2701 \times 1200 = 13.945\,524\,1627 \end{align}$$

()

The Bohlen–Pierce delta scale is based on the tritave and the 7:5:3 "wide" triad () and the 9:7:5 "narrow" triad () (rather than the conventional 4:5:6 triad). Notes include:

1:1

25:21

9:7

75:49

5:3

9:5

15:7

7:3

25:9

3:1

See also

• Alpha scale
• Beta scale
• Gamma scale

Further reading

• Bohlen, Heinz: "13 Tonstufen in der Duodezime", Acustica, vol. 39 no. 2, S. Hirzel Verlag, Stuttgart, 1978, pp. 76–86.
